Industrial Power Supply A-450FGF Series

The A-450FGF-X series is a 450-watt air-cooled metal-enclosed industrial power supply. Adopting a wide AC&DC input voltage, the entire series provides an output voltage line of 12V, 15V, 24V, 27V, 36V, and 48V for optional. It can be adapted to different load applications and meet various industrial application requirements. Besides, the EMC and safety regulations comply with the IEC/EN/UL62368 standards. High conversion efficiency, compact housing design, good heat dissipation, and all-around protection guarantee the high reliability and stability of this power supply.

Product Features:

— AC input range selectable by switch
— High efficiency, long life, and high reliability
— Output protections: SCP/OVP/OLP/OTP
— Operating temperature: -25℃~+70℃
— LED indicator for power on
— 100% full load burn-in test
— Low profile, 30mm
— Forced air cooling by built-in DC fan
— 3-year warranty

Model List:

Mechanical Specification:
