LED Drivers 25W 36W 60W 120W 150W 200W 250W 300W 400W 600W
Order info: LED Drivers 25W 36W 60W 120W 150W 200W 250W 300W 400W 600W
| Item No. | Size & NW | Input Voltage | DC Output | Features |
| WTP-8500SK-500W Standard 500W LED Driver |
240x125x65(mm) 1.36 (kg/pcs) 12 pcs / carton |
110VAC / 220VAC By setting in factory |
DC12V / 42A DC24V / 21A DC36V / 14A DC48V / 11A |
1) Overload protection
2) Output voltage: ±10% 3) Ball bearing fan |
| WTP-8600SK-600W Standard 600W LED Driver |
240x125x65(mm) 1.36 (kg/pcs) 12 pcs / carton |
110VAC / 220VAC By setting in factory |
DC12V / 50A DC24V / 25A DC36V / 17A DC48V / 13A |
1) Overload protection
2) Output voltage: ±10% 3) Ball bearing fan |
| WTP-3400SK-400W Standard 400W LED Driver |
215x115x50(mm) 0.92 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
DC 5V / 70A DC12V / 33A DC24V / 16A DC36V / 11A DC48V / 8A |
1) Overload protection
2) Output voltage: ±10% 3) Thick fan, Long life |
| WTP-3360SK-360W Standard 360W LED Driver |
215x115x50(mm) 0.92 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
DC 5V / 60A DC12V / 30A DC24V / 15A DC36V / 10A DC48V / 7.3A |
1) Overload protection
2) Output voltage: ±10% 3) Thick fan, Long life |
| WTP-3300SK-300W Standard 300W LED Driver |
200x110x50(mm) 0.87 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
DC12V / 25A DC24V / 12A |
1) Overload protection
2) Output voltage: ±10% |
| WTP-3250SK-250W Standard 250W LED Driver |
200x110x50(mm) 0.86 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
DC 5V / 50A DC12V / 20A DC24V / 10A |
1) Overload protection
2) Output voltage: ±10% 3) Type B: 36V6A / 48V5A |
| WTP-3200SK-200W Standard 200W LED Driver |
200x110x50(mm) 0.84 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
DC 5V / 40A DC12V / 16A DC24V / 8A |
Output voltage: ±10%
|
| WTP-3150SK-150W Standard 150W LED Driver |
200x98x38(mm) 0.60 (kg/pcs) 25 pcs / carton |
110VAC / 220VAC By switch |
DC5V12.5A DC12V / 15A DC24V / 6.3A |
1) Output voltage: ±10%
2) Type B: 36V5A / 48V3A |
| WTP-3120SK-120W Standard 120W LED Driver |
159x98x38(mm) 0.55 (kg/pcs) 40 pcs / carton |
110VAC / 220VAC By switch |
DC5V20A DC12V / 8.3A DC12V / 10A DC24V / 5A |
1) Output voltage: ±10%
2) Type B: 36V5A / 48V3A |
| WTP-860SK-12 WTP-872SK-24 Mini 60W LED Driver |
130x98x38(mm) 0.39 (kg/pcs) 46 pcs / carton |
85-277VAC | 12V5A ——- 5V10A 24V3A |
Output voltage: ±10%
|
| WTP-825SK-12 WTP-825SK-24 Mini 25W LED Driver |
85x58x33(mm) 0.16 (kg/pcs) 100 pcs / carton |
85-277VAC | DC12V2A —— DC24V1A |
Output voltage: ±10%
|
| WTP-3200DL2-200W Standard 200W LED Driver 2 channel output voltage |
200x110x50(mm) 0.86 (kg/pcs) 20 pcs / carton |
110VAC / 220VAC By switch |
5V10A, 24V6A —— 12V5A, 24V6A |
Output voltage: ±10%
|
| WTP-3200DL2-120W Standard 120W LED Driver 2 channel output voltage |
200x98x38(mm) 0.62 (kg/pcs) 25 pcs / carton |
110VAC / 220VAC By switch |
5V3A, 24V5A —— 12V3A, 24V4A |
Output voltage: ±10%
|
| WTP-3400FY-400W Waterproof 400W LED Driver |
250x163x55(mm) 1.34 (kg/pcs) 18 pcs / carton |
110VAC / 220VAC By switch |
5V70A 12V33A 24V17A 36V11A 48V8A |
1) Overload protection
2) Output voltage: ±10% 3) Thick fan, Long life |
| WTP-3350FY-350W Waterproof 350W LED Driver |
250x163x55(mm) 1.33 (kg/pcs) 18 pcs / carton |
110VAC / 220VAC By switch |
5V60A 12V30A 24V15A 36V10A 48V7.3A |
1) Overload protection
2) Output voltage: ±10% 3) Thick fan, Long life |
| WTP-3300FY-300W Waterproof 300W LED Driver |
235x139x63(mm) 1.24 (kg/pcs) 21 pcs / carton |
110VAC / 220VAC By switch |
5V50A 12V25A 24V12A |
Output voltage: ±10%
|
| WTP-3250FY-250W Waterproof 250W LED Driver |
235x139x63(mm) 1.23 (kg/pcs) 21 pcs / carton |
110VAC / 220VAC By switch |
5V40A 12V20A 24V10A |
Output voltage: ±10%
|
Tags: LED Drivers
