Allcoola Digital LED Strips

WS2815 | WS2813 | SK6812-4020 | APA102 | DMX512 RGB RGBW Digital LED Strips | SMD2110 | RGB+CCT

90 Piexl WS2811 Programmable Digital Led Strip Light

Programmable

90 Piexl WS2811 Programmable Digital Led Strip Light

Overview:

WS2811 Programmable led strips, 90led/m, Control IC was outside the LED, 30pixel/m, 12V, 21.6w/m, 12mm white or black PCB, 15cm JST connector;

Data sheet:

  Product:   12V 90led WS2811 Digital Led Strip Light
  Item No.:   WTP-2811X90-12V
  LED:   WS2811-SMD5050-RGB, 90led/m
  View angle:  120°
  IC Chip:  WS2811
  Input voltage:  12V
  Power:  21.6w/m
  Size:  5000x12x2.5(mm), 5m/roll

Features

1) Addressable DC12V WS2811 LED Strips; Long life span 50,000+ hours;
2) Super bright 5050 SMD top LED, high intensity and reliability;
3) Addressable, each IC control three SMD5050-RGB LEDs;
4) WS2811 has 3 Wires input and output: Data, GND and Power+;
6) 3 leds one cut;
7) PWM 2KHz/m, Data transmit up to 800kbps, 256 grayscale effect;

90pixels/m

Application:

> Widely used for home decoration use, hotels, clubs, shopping malls
> Architectural decorative lighting, boutique atmosphere lighting
> Extensively applied in background lighting, concealed lighting, channel letter lighting
> Emergency & security lighting, advertisement sign lighting
> Decorative lights for holiday, event, show exhibition
> Applicable for automobile and bicycle decoration, border or contour lighting

Remark:

1) Do not use any acidic, alkaline adhesive fixing Product;
2) It is prohibited to make products with a hard object collision, friction;
3) Do not use your fingers to press LED;
4) Don’t make positive and negative reversed;
5) Don’t install when product is working;
6) Installation, repair and maintenance must be made by professional Person;
7) Before you use them make sure the power supply voltage to meet the requirements and wire connection correctly.

 Order Info: (IP20/IP65/IP67/IP68)

SN Model Number LED Qty
(led/m)
Pixel Qty
(Pixel/m)
PCB Width
(mm)
PCB
Color
Operate
Voltage
Power
(w/m)
Packing
(m/roll)
1 WTP-2811RGBx30 30led/m 30 10 W/B 12V 6.6 5
2  WTP-2811RGBx60 60led/m 6010 W/B 12V 13.2 5
3 WTP-2811RGB1x90 90led/m90 12W/B 12V 21.6 5
4  WTP-2811RGBx90P 90led/m90 15 W/B 12V 24.0 5

Photos
